Low Voltage Switchgear Systems
Low-Voltage Switchgear Systems For Infrastructure
System Range
TRI TECH is a modular system range of power distribution boards designed specifically for infrastructures up to 6300 A.
TRI Tech's Low Voltage products are optimized for safe and reliable power distribution.
It consists of:
Switching and protective devices.
The modular enclosure system.
The control panel complete with planning and calculation tools.
The system range integrates switching and protective devices, mounting and enclosure systems and control panel components into a coherent, cost-effective system.
The Low voltage switchgear that have been manufacturing according to IEC 60439. Available from Form 1 to Form 4, the system can be designed to comply to any applicable installation standards and all relevant switchgear combinations to the respective protection type up to 6300 A.
Product Features
Clear segregation into functional areas up to Form 4b.
Enclosures for combination- and separate mounting.
Enclosure protection IP31 or IP54.
Main busbars at the top up to 4000 A.
Main busbars at the rear bottom up to 7000A.
Mains system types TN-C, TN-C-S, TN-S, TT, IT.
Products
Incomer Feeders, Outgoing Feeders
Bus Coupler Panels, ATS Panels
Load takeoff panels.
3 or 4 pole circuit-breakers
Cable or busbar trunking connection from top or bottom
